Product Details
Machine type: | LW-388J | Glue box heating power: | 1.5kw | |
Dimension: | 5700*900*1550mm | Glue box transmission power: | 0.37kw | |
Weight: | 1.57t | Plate preheating power: | 0.25kw | |
Total power: | 12.77kw | Conveyer motor power: | 2.2kw | |
Voltage: | 380V 50Hz. | Endcutting motor power: | 0.37kw*2(12000r/min) | |
Air pressure: | 0.7-0.9MPa | Rough trimming motor power: | 0.75kw*2(18000r/min) | |
Sheet Length: | ≥80mm | Fine trimming motor power: | 0.75kw*2(18000r/min) | |
Sheet Width: | ≥40mm | Corner Rounding motor power: | 0.3kw*2(18000r/min) | |
Sheet Thickness: | 12-55mm | Polishing motor power: | 0.18kw*2 | |
Edge Band Thickness: | 0.4-3mm | |||
Feed Rate: | (16-18-20)m/min |
